10inc wide screen touch panel, 16M colors, COM x 2, ETH x 1, USB host / device, RTC, DC24V
Range of product Easy Harmony ET6
Product or component type: Touch panel screen
Software designation: Vijeo Designer Basic
Operating system: VxWorks
Processor name: ARM Cortex-A8
Display size: 10 inch
Display type: Colour TFT LCD
Display colour: 16 million colours
Display resolution: 1024 x 600 pixels WSVGA
Touch panel: Single touch analogue resistive
Brightness: 16 levels
Character font: ASCII (European characters)
13. [Us] rated supply voltage: 24 V DC +/- 20 %
Inrush current: 30 A
Local signalling:
Status LED green, steady for operating
Status LED orange, steady for software starting up
Status LED red, steady for power supply (ON)
Status LED, off for power supply (OFF)
Power consumption in W: 11 W
Number of pages: 200 application pages
Processor frequency: 800 MHz
Port Ethernet: 10/100BASE
Width: 270.5mm
Height: 200.5mm
Depth: 47mm
Net weight: 0.98Kg
10inc wide screen touch panel, 16M colors, COM x 2, ETH x 1, USB host / device, RTC, DC24V
Range of product Easy Harmony ET6
Product or component type: Touch panel screen
Software designation: Vijeo Designer Basic
Operating system: VxWorks
Processor name: ARM Cortex-A8
Display size: 10 inch
Display type: Colour TFT LCD
Display colour: 16 million colours
Display resolution: 1024 x 600 pixels WSVGA
Touch panel: Single touch analogue resistive
Brightness: 16 levels
Character font: ASCII (European characters)
13. [Us] rated supply voltage: 24 V DC +/- 20 %
Inrush current: 30 A
Local signalling:
Status LED green, steady for operating
Status LED orange, steady for software starting up
Status LED red, steady for power supply (ON)
Status LED, off for power supply (OFF)
Power consumption in W: 11 W
Number of pages: 200 application pages
Processor frequency: 800 MHz
Port Ethernet: 10/100BASE
Width: 270.5mm
Height: 200.5mm
Depth: 47mm
Net weight: 0.98Kg
